Schneider Electric Frequency converter 100-240V E1ph A3ph SD326DU25S2
Price in EUR including VAT
Delivered between Tue, 14.10. and Thu, 16.10.
free shipping
Product details
Step motor amplifier of the Lexium SD326 series. The SD326 is a universally applicable step motor amplifier. In combination with selected 3-phase stepper motors, it creates a very compact and powerful drive system. Setpoints are typically provided and monitored by a higher-level PLC or motion controller. This amplifier features a pulse/direction interface without speed monitoring. The peak current is up to 2.5 A. The supply voltage is switchable between 115/230 VAC, and an EMC filter is integrated.
Power | 0.27 kW |
Protection type (IP code) | IP20 |
Item number | 30343760 |
Manufacturer | Schneider Electric |
Category | Frequency converters |
Manufacturer no. | SD326DU25S2 |
Release date | 28.4.2023 |
Input phase number | 1 x |
Output phase number | 3 x |
Electric current output | 2.50 A |
Power | 0.27 kW |
Relative symmetrical mains frequency tolerance | 5 % |
Relative symmetrical mains voltage tolerance | 10 % |
Protection type (IP code) | IP20 |
Country of origin | Germany |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Width | 7.20 cm |
Depth | 14 cm |
Height | 14.50 cm |
Product Safety |
