Siemens Dig.Industr. SIPLUS S7-1500 6AG1526-2BF00-2AB0

Manufacturer: Siemens Dig.Industr.
Designation: SIPLUS S7-1500 8x24VDC/2A
Type: 6AG1526-2BF00-2AB0
Supply voltage (DC): 19.2..28.8 V
Type of supply voltage: DC
Number of digital outputs: 8
Configurable digital outputs: yes
Type of digital output: Transistor
Output current: 2 A
Permissible output voltage: 0..28.8 V
Type of output voltage: DC
Short-circuit protection for outputs: yes
Redundancy capability: yes
Suitable for safety functions: yes
SIL according to IEC 61508: 3
Performance Level according to EN ISO 13849-1: Level e
Associated operating equipment (Ex ia): no
Associated operating equipment (Ex ib): no
Explosion protection category for gas: ATEX Gas-Ex protection, Cat. 3G
Explosion protection category for dust: none
Width: 35 mm
Height: 147 mm
Depth: 129 mm

Further details:
SIPLUS S7-1500 F-DQ 8x24VDC/2A based on 6ES7526-2BF00-0AB0 with Conformal Coating, -30 to +60 °C, F-Digital output module, 35 mm width, up to PL E (ISO 13849-1) / SIL3 (IEC 61508). SIMATIC ET 200MP is a modular, scalable, and universally applicable peripheral system in IP20 and offers the same system advantages as the S7-1500. It allows for the shortest bus cycle times and fastest response times even with large quantities. The decentralized peripheral system is particularly easy to install, wire, and commission. Due to its scalable design, you can precisely align the peripheral station to the specific needs on-site. Like the CPU, the digital output modules are also protected against extreme environmental conditions. With 100% Conformal Coating, they resist biological, chemical, and mechanically active substances, condensation, frost, and harmful gases. No matter the conditions, your digital signals will be reliably output.
EAN: 4047618071905.
