Striebel & John Fuse Load Break Switch ZE573M

Manufacturer: Striebel & John
Description: Fuse Load Break Switch ZHBM + EFM NH-2 3P
Type: ZE573M
Design: Fuse Load Break Switch
Double Break: No
Rated Continuous Current Iu: 400 A
Rail Center Distance 40 mm: No
Rail Center Distance 50 mm: No
Rail Center Distance 60 mm: No
Rail Center Distance 100 mm: No
Rail Center Distance 185 mm: Yes
Max. Rated Operating Voltage Ue for AC: 400 V
Connection Type Main Circuit: Screw Connection
Number of Poles: 3
Size of Fuse Insert: NH2
Tripped Indication: None

The InLine II ZLBM / ZHBM device generation offers you optimal stability and maximum safety in the power distribution network. They switch rated currents from 160 A to 630 A, ensuring the highest level of personal protection during operation and maintenance of your switchgear. ABB provides this series in a 3-pole variant, which has been tested according to EN / IEC 60947-3. Installation is more space-saving and flexible than ever, thanks to horizontal and vertical mounting options. We also ensure easy and safe installation of current transformers and the replacement of NH fuse inserts. This series is suitable for phase rails with a distance of 185 mm. EAN: 4011617429661.
