Vortice Filo MF 150
Only 2 pieces in stock at supplier
Product details
Dimensions and technical details: 220-240 Volt ~ 50 Hertz. Various options available. Housing colour: white. Housing material: UV-resistant ABS plastic. Nominal size: 150 mm. Max. wattage: 28 W. Max. current consumption: 0.15 A. Revolutions per minute: 2100. Speed levels: 1. Max. airflow rate: 335 m³/h. Total pressure Pmax: 59 Pa. Sound pressure level Lp-3m: 40.1 dB(A). Max. temperature for continuous operation: 50°C. Protection code: IPX4. Protection class: II. Weight: 0.97 kg. Thermal overload protection. Integral shutter flap prevents cold air from infiltrating. Used to extract air from the inside directly to the outside. Mounting options: wall mounting (horizontal, vertical, diagonal position). Optional condensation gasket for ceiling installation kit sold separately.
Type: Equipment
Filo MF 150 LL: Standard
Filo MF 150 T LL: Time delay (adjustable 2-30 min)
Filo MF 150 THC.
Airflow | 370 m³/h |
Suitable for pipe diameter | 150 mm |
Power | 28 W |
Ventilation fan type | Duct fan + centrifugal fan |
Item number | 17544547 |
Manufacturer | Vortice |
Category | Ventilation fan |
Manufacturer no. | 11176 |
Release date | 22.11.2021 |
Colour | White |
Exact colour description | White |
Material group | Plastic |
Material | Plastic |
Ventilation fan type | Duct fan + centrifugal fan |
Airflow | 370 m³/h |
Noise emission | 40 dB |
Suitable for pipe diameter | 150 mm |
Power supply | Electrical connection |
Mains voltage | 230 V |
Power | 28 W |
Country of origin | Germany, Italy |
CO₂-Emission | |
Climate contribution |
Length | 9.60 cm |
Width | 21.40 cm |
Height | 21.40 cm |
Weight | 970 g |
