Wago GmbH & Co. KG Power Supply Unit 787-1216
Only 4 pieces in stock at supplier
Product details
WAGO GmbH & Co. KG Power Supply Unit 787-1216
Manufacturer: WAGO GmbH & Co. KG
Designation: Power Supply Epsitron
Type: 787-1216
Supply Voltage Type: AC/DC
Output Voltage: 22..26 V
Max. Output Current: 4.2 A
Adjustable Output Voltage: yes
Nominal Output Voltage: 24 V
Nominal Output Current: 4.2 A
Short-Circuit Proof: yes
Rated Supply Voltage at AC 50 Hz: 85..264 V
Rated Supply Voltage at AC 60 Hz: 85..264 V
Rated Supply Voltage at DC: 125..375 V
Regulated Output Voltage: yes
Power Output: 100 W
Stabilized: yes
Electrical Connection Type: Spring Clamp Connection
DIN Rail Mounting Possible: yes
Wall Mounting Possible: yes
Suitable for Series Installation: yes
Width in Division Units: 6
Direct Mounting Possible: no
Width: 108 mm
Height: 90 mm
Depth: 90 mm
Suitable for Safety Functions: no
Protection Class (IP): IP20
WAGO GmbH & Co. KG Power Supply Unit 787-1216: additional details
Primary switched power supply
Compact 1-phase
Output Voltage DC 24 V
Output Current 4.2 A
DC-OK LED
Features: Primary switched power supply. Step profile for standard-compliant installation in the distribution board. Screw connections optimal for alternative installation in the system distributor or device installation. Plug-in picoMAX® connection technology (tool-free). Can be connected in parallel, can be connected in series. Galvanically isolated output voltage (SELV) according to EN 60335-1 and UL 60950-1 PELV according to EN 60204.
EAN: 4055143907804.
Nominal current | 4.20 A |
Nominal voltage | 24 V |
Number of outlets | 1x |
Protection type (IP code) | IP20 |
Item number | 22657606 |
Manufacturer | Wago |
Category | Mobile power distributors |
Manufacturer no. | 612075 |
Release date | 12.10.2022 |
External links |
Colour | Grey |
Exact colour description | Grey |
Nominal current | 4.20 A |
Nominal voltage | 24 V |
Number of outlets | 1x |
mounting type | Wall-mounted |
Actuator Type | Spring-cage connection |
Power | 100 W |
Input voltage | 85 - 264 V |
output voltage | 24V |
Protection type (IP code) | IP20 |
Country of origin | China |
CO₂ emissions | 17,29 kg |
Climate contribution | EUR 0,43 |
Items per sales unit | 1 pcs. |
Width | 108 mm |
Length | 56 mm |
Height | 90 mm |
Product Safety |
Length | 13 cm |
Width | 11 cm |
Height | 7 cm |
Weight | 330 g |
