Merten Switch/Changeover Switch One MEG3136-0000

Manufacturer: Merten
Description: Switch/Changeover Switch One with Orientation Light
Type: MEG3136-0000
Circuit Type: Switch/Changeover Switch with Orientation Light, Single Pole
Operation Type: Rocker/Button
Assembly: Flush-mounted Unit
Push Button: No
Number of Actuation Rockers: 1
Mounting Type: Flush-mounted
Fixing Type: Claw/Screw Fixing
With Mounting Plate: Yes
Material: Metal/Plastic
Material Quality: Other
Halogen-free: Yes
Antibacterial Treatment: No
Surface Protection: Untreated
Surface Finish: Matt
Text Field/Labeling Area: No
Lighting: LED Locator Light
Lighting Function: Orientation
Lighting Type: LED, replaceable
Suitable for Protection Class (IP): IP20
Nominal Voltage: 250 V
Rated Current: 10 A
Switching Current for Fluorescent Lamps: 10 AX
Feedback Contact: No
Connection Type: Plug Terminal
Heating Switch: No
Washing Machine Switch: No
Device Width: 73 mm
Device Height: 73 mm
Device Depth: 37 mm
Installation Depth: 28 mm
Min. Depth of Device Box: 40 mm
Compatible with Apple HomeKit: No
Compatible with Google Assistant: No
Compatible with Amazon Alexa: No
IFTTT Support Available: No

Merten Switch/Changeover Switch One MEG3136-0000: Additional Details
Features: Front-side retrofitting of QuickFlex lighting modules without switch disassembly. Front-side measurement and testing contacts accessible without switch disassembly. Quick-thread screws for claw fixing. Recessed claws with return spring. High-gloss galvanized support ring insulated to the claw. With claw and screw fixing. With plug terminals. To be completed with rockers for Switch/Button System M.
