Schneider Electric FISwitch 4P 63A 500mA Type
Price in EUR including VAT
free shipping
Residual current circuit breaker Acti 9 iID, 1.5kA (IEC/EN 61008-1). 4-pole, rated current 63A, earth fault sensitivity 500mA, earth fault protection class Type A, operating voltage (Ue) 400V AC, insulation voltage (Ui) 500V AC. Provides additional protection against direct contact (30mA). Fault protection against indirect contact, e.g., in case of insulation faults (100mA, 300mA). Fault protection in construction site distribution boards (500mA). Switching and isolating of circuits. Snap-action for low-wear switching of contacts. With mechanical front-facing fault indication (VisiTrip) to show tripping due to overload or short circuit. Safe contact indication (VisiSafe) of the residual current circuit breaker, with green indication ensuring voltage-free safety on the outgoing side. Test button for regular function checks. Double connection terminals for connection of cables or busbars on both sides. Easy removal of the individual device when a busbar is installed, thanks to the front-accessible fastening element. Additional snap-on auxiliary modules (optional) - undervoltage release (iMN), overvoltage release (iMSU), working current release (iMX), auxiliary switch for status indication (iOF), fault indication switch (iSD). Tool-free mounting on the left side of the device. Color shade RAL 9003. The residual current circuit breaker iID complies with the following standards: IEC/EN 61008-1 and IEC/EN 60947-2. Furthermore, this series is VDE certified.
Circuit breaker type | Fault current circuit breaker |
Length | 7 mm |
Width | 72 mm |
number of poles | 4 |
Mounting type | Top-hat rail |
Item number | 12897800 |
Manufacturer | Schneider Electric |
Category | Residual-current device |
Manufacturer no. | A9Z26463 |
Release date | 12.3.2020 |
External links |
Colour | White |
Exact colour description | RAL 9003 |
Circuit breaker type | Fault current circuit breaker |
Mounting type | Top-hat rail |
number of poles | 4 |
Tripping characteristic | A |
Rated current | 63 A |
Rated current | 0.5 A |
Rated voltage | 400 V |
voltage type | AC |
Rated insulation voltage Ui | 500 V |
Residual current (rated differential current) | 0.50 A |
Protection type (IP code) | IP20 |
Country of origin | China |
Manufacturer commitment | RE100, SBTi |
Manufacturer compensation | According to RE100, the manufacturer Schneider Electric fully compensates for its energy consumption, leading to a reduction in emissions. |
CO₂-Emission | |
Climate contribution |
Items per sales unit | 1 Piece |
Length | 7 mm |
Width | 72 mm |
Height | 91 mm |
Weight | 370 g |
