Siemens Dig.Industr. Circuit Breaker 5SL6202-7

Manufacturer: Siemens Dig.Industr.
Designation: Circuit Breaker C2A, 2-pole
Type: 5SL6202-7
Installation Depth: 70 mm
Tripping Characteristic: C
Total Number of Poles: 2
Number of Protected Poles: 2
Rated Current: 2 A
Rated Voltage: 400 V
Rated Short-Circuit Capacity Icn according to EN 60898 at 230 V: 6 kA
Voltage Type: AC
Rated Short-Circuit Capacity Icn according to EN 60898 at 400 V: 6 kA
Rated Short-Circuit Capacity Icu according to IEC 60947-2 at 230 V: 6 kA
Rated Short-Circuit Capacity Icu according to IEC 60947-2 at 400 V: 6 kA
Frequency: 50 Hz
Energy Limitation Class: 3
Flush Mounting: No
Switching Neutral Conductor: No
Overvoltage Category: 3
Degree of Pollution: 2
Additional Devices Possible: Yes
Width in Division Units: 2
Protection Class (IP): IP20
Ambient Temperature During Operation: -25..45 °C
Connectable Conductor Cross-Section Multi-Wire: 0.75..25 mm²
Connectable Conductor Cross-Section Single-Wire: 0.75..25 mm²
Explosion Protected: No

Siemens Dig.Industr. Circuit Breaker 5SL6202-7: Additional Details
Circuit breaker 400V 6kA, 2-pole, C, 2A.
SENTRON 5SL circuit breakers provide safe short-circuit and overload protection for standard applications in residential and commercial buildings. Tool-free installation and removal of the device. Simple wiring of the supply through the rear-mounted busbar. The 5SL circuit breakers are available in 1-, 2-, 3-, 4-pole configurations, as well as in 1+N and 3+N versions, along with various special types. The extensive accessories, such as auxiliary switches, allow for diverse functional expansions. Simply safe with SENTRON protective devices.
EAN: 4001869388410.
