Surge protection module for signal technology
Nominal voltage DC 5 V
For 2 signal paths with common grounding
For interfaces with high transmission rates
2-stage
Width 6 mm
2.50 mm²

Short description:
Surge protection devices for systems and equipment in information technology with a voltage range up to 60 V (excluding special solutions, e.g., telephone systems with ringing voltage). Surge protection is also possible in terminal blocks for 35 mm mounting rails. Only 6 mm wide, multi-stage surge protectors in terminal block form from the 792-80x series provide space-saving, cost-effective protection for control and bus technology, such as LON networks, PROFIBUS networks, binary signals, etc.

Features:
Protection of your system against surges.
Space-saving due to narrow design.
Cost savings by preventing downtime.
High operational reliability and system availability.
